Gazepoint AOI Perturbation and Uncertainty

Architecture

This workflow is deliberately thin. gp3tools handles Gazepoint-specific column names and coordinate units; eyeprocess owns AOI perturbation, assignment stability, feature recomputation, statistical propagation, and visualization. The wrapper does not create a second scientific implementation.

When to use

Use the adapter when Gazepoint samples or fixations must be tested against small, defensible AOI-boundary changes. Do not use it to search for a favorable AOI or to replace calibration, screen-coordinate, or tracking-quality checks.

Synthetic normalized Gazepoint-style data

set.seed(20260918)
aois <- data.frame(
  aoi_id = c("headline", "image", "claim", "disclosure", "cta"),
  xmin = c(.10, .30, .30, .30, .68), xmax = c(.40, .70, .70, .70, .92),
  ymin = c(.08, .19, .36, .50, .60), ymax = c(.18, .34, .48, .59, .71)
)
gaze <- data.frame(
  sample_id = 1:80, participant = rep(paste0("p", 1:8), each = 10),
  trial = rep(rep(1:2, each = 5), 8),
  FPOGX = pmin(1, pmax(0, runif(80, .08, .94))),
  FPOGY = pmin(1, pmax(0, runif(80, .06, .74))),
  duration = runif(80, .06, .18)
)

Audit the adapter boundary

Normalized coordinates are not treated as pixels implicitly. Screen dimensions must be supplied before conversion.

audit <- audit_gazepoint_aoi_uncertainty(
  gaze, aois, gaze_x_col = "FPOGX", gaze_y_col = "FPOGY",
  coordinate_unit = "normalized", screen_width_px = 1920, screen_height_px = 1080
)
audit$overview
#> # A tibble: 1 × 5
#>   n_rows n_missing_coordinates n_aois coordinate_unit core_status
#>    <int>                 <int>  <int> <chr>           <chr>
#> 1     80                     0      5 normalized      valid

Run the vendor-neutral sensitivity workflow

result <- run_gazepoint_aoi_sensitivity(
  gaze, aois, gaze_x_col = "FPOGX", gaze_y_col = "FPOGY",
  coordinate_unit = "normalized", perturbation_unit = "deg",
  dilations = c(.25, .50, 1.00), erosions = .25,
  translations_x = .50, translations_y = .50,
  translations_xy = list(c(.25, -.25)),
  screen_width_px = 1920, screen_height_px = 1080,
  viewing_distance = 60, physical_screen_size = c(53.1, 29.9),
  observation_id_col = "sample_id", participant_col = "participant",
  trial_col = "trial", duration_col = "duration",
  observation_level = "sample",
  overlap_policy = "ambiguous", quality_rules = list(missing = "preserve")
)
#> Warning: No time_col supplied; first_fixation is returned as NA rather than
#> inferred from row order.
#> Warning: No time_col supplied; first_fixation is returned as NA rather than
#> inferred from row order.
#> Warning: No time_col supplied; first_fixation is returned as NA rather than
#> inferred from row order.
#> Warning: No time_col supplied; first_fixation is returned as NA rather than
#> inferred from row order.
#> Warning: No time_col supplied; first_fixation is returned as NA rather than
#> inferred from row order.
#> Warning: No time_col supplied; first_fixation is returned as NA rather than
#> inferred from row order.
#> Warning: No time_col supplied; first_fixation is returned as NA rather than
#> inferred from row order.
#> Warning: No time_col supplied; first_fixation is returned as NA rather than
#> inferred from row order.
result$core_result$stability$overall
#>                                 perturbation_id n_total n_comparable
#> baseline                               baseline      80           80
#> dilate_0.25_deg                 dilate_0.25_deg      80           80
#> dilate_0.5_deg                   dilate_0.5_deg      80           80
#> dilate_1_deg                       dilate_1_deg      80           80
#> erode_0.25_deg                   erode_0.25_deg      80           80
#> shift_x_0.5_deg                 shift_x_0.5_deg      80           80
#> shift_xy_0.25_-0.25_deg shift_xy_0.25_-0.25_deg      80           80
#> shift_y_0.5_deg                 shift_y_0.5_deg      80           80
#>                         proportion_unchanged proportion_newly_assigned
#> baseline                              1.0000                    0.0000
#> dilate_0.25_deg                       0.9500                    0.0500
#> dilate_0.5_deg                        0.9250                    0.0750
#> dilate_1_deg                          0.7625                    0.1500
#> erode_0.25_deg                        0.9000                    0.0000
#> shift_x_0.5_deg                       0.9875                    0.0000
#> shift_xy_0.25_-0.25_deg               0.9125                    0.0250
#> shift_y_0.5_deg                       0.9250                    0.0125
#>                         proportion_lost proportion_reassigned
#> baseline                         0.0000                0.0000
#> dilate_0.25_deg                  0.0000                0.0000
#> dilate_0.5_deg                   0.0000                0.0000
#> dilate_1_deg                     0.0000                0.0875
#> erode_0.25_deg                   0.1000                0.0000
#> shift_x_0.5_deg                  0.0125                0.0000
#> shift_xy_0.25_-0.25_deg          0.0625                0.0000
#> shift_y_0.5_deg                  0.0625                0.0000

translations_xy is forwarded unchanged to the vendor-neutral core; gp3tools does not implement a separate translation engine. The complete eyeprocess result remains unchanged inside result$core_result; the outer object records Gazepoint source columns and unit-conversion settings.

Visual output

plot_gazepoint_aoi_sensitivity(result, "assignment")

Other delegated plot families are perturbations, coefficient, and surface.

Plot-to-question map

Adapter plot type	Delegated scientific question	Inspect together with
"perturbations"	Which observations cross a boundary when geometry changes?	adapter settings, perturbation ID, overlap policy
"assignment"	How much of the Gazepoint-to-AOI mapping changes?	unchanged/new/lost/reassigned proportions
"coefficient"	Does the same model change materially?	coefficient intervals, convergence, model N
"surface"	Where does sensitivity concentrate across joint geometry changes?	the declared two-dimensional perturbation plan

The adapter passes plot arguments through to the corresponding eyeprocess function. A manuscript-ready workflow normally combines one geometry/reassignment figure, assignment stability, and coefficient stability; use the surface only when a two-dimensional perturbation grid was part of the declared analysis plan.

plot_gazepoint_aoi_sensitivity(
  result, "perturbations",
  perturbation_id = "dilate_0.5_deg",
  data = result$core_result$assignments
)
plot_gazepoint_aoi_sensitivity(result, "assignment")
plot_gazepoint_aoi_sensitivity(result, "coefficient", term = "condition")
plot_gazepoint_aoi_sensitivity(surface_result, "surface")

Gazepoint AOI pre-run checklist

For a fillable preregistration-style template that records source columns, coordinate conversion, perturbation choices, observation level, failure handling, and reporting fields, see the companion Gazepoint AOI Sensitivity Analysis Plan article.

Before calling the adapter, confirm:

1. the exact Gazepoint x/y source columns;
2. whether coordinates are normalized or pixels;
3. screen width/height for normalized-to-pixel conversion;
4. physical screen size and viewing distance for degree-based perturbations;
5. whether rows are samples or fixations;
6. the perturbation grid, overlap policy, and boundary policy;
7. the fixed downstream model specification in the delegated eyeprocess callback.

The adapter never infers these scientific choices from the desired result.

Gazepoint AOI troubleshooting

Use audit_gazepoint_aoi_uncertainty() first when units or source columns are uncertain. Once the adapter boundary is valid, troubleshoot the delegated core result in this order: geometry, assignments, feature denominators, then model callback.

Symptom	First check	Do not do
Normalized coordinates rejected	screen dimensions and coordinate_unit	Treat 0-1 values as pixels
Geometry branch fails	result$core_result$grid_result$audit	Fall back silently to the older margin-sensitivity path
Many ambiguous assignments	perturbed layout and core reassignment matrix	Resolve overlap by AOI order
Sample count is zero	valid sample denominator	Recode missing gaze as zero
Sample count is missing	missing source coordinates	Treat the trial as observed non-inspection
Model callback fails/non-converges	core failures/models tables	Report it as a valid null effect
Model N changes	core inference stability	Report only coefficient direction

A reporting sentence should identify the original Gazepoint columns and coordinate unit before describing AOI robustness, because otherwise the perturbation scale is not reproducible.

Adapter/core API links

• audit_gazepoint_aoi_uncertainty() validates the Gazepoint-to-core boundary.
• run_gazepoint_aoi_sensitivity() delegates the complete workflow to eyeprocess.
• plot_gazepoint_aoi_sensitivity() delegates all four plot families.
• Use the eyeprocess AOI troubleshooting guidance for geometry, denominator, convergence, and model-N interpretation.

Gazepoint interpretation clinic

Use the adapter only after source coordinates and screen geometry are explicit. For normalized Gazepoint samples, declare observation_level = "sample"; for fixation exports or fixation centroids, declare "fixation".

Pattern	Interpretation	Action
Assignments and model stable	Stable within the declared AOI envelope	Report both layers and the screen/viewing geometry
Assignments unstable, model stable	Geometry changes mapping without materially changing the model result	Inspect reassignment matrices and AOI-level stability
Model unstable	Substantive inference depends on geometry and/or branch-specific case loss	Inspect coefficient intervals, convergence, and model N
Adapter/core failure	The branch is non-evaluable	Keep the failure visible; do not fall back to the older margin-sensitivity implementation

At sample level, a zero count means valid gaze samples existed but none landed in that AOI. If all coordinates for a participant/trial are missing, the count remains missing rather than becoming zero.

Figure set for reviewer handoff

For a compact reviewer/manuscript package, pair the Gazepoint adapter settings with: (1) a geometry/reassignment diagnostic, (2) assignment stability, and (3) coefficient stability. Add a robustness surface only for a prespecified joint perturbation grid. The visual layer should always be accompanied by the core perturbation audit, failures, convergence, and model-N summaries.

Reporting example

Gazepoint normalized coordinates were converted using the declared screen dimensions, and AOI sensitivity was evaluated in degrees of visual angle. Sample-level assignments were recomputed across the nominal and perturbed geometries using explicit ambiguity handling. We report assignment stability, coefficient ranges/intervals, convergence, and model-N variation; failed branches were retained in the audit trail.

Interpretation and limitations

A high unchanged-assignment proportion means the result is stable only with respect to the declared perturbations. It is not a probability that an AOI or scientific conclusion is true. Overlap remains explicit ambiguity by default; missing coordinates remain missing; failed branches and non-converged models remain in the core audit trail. When a model callback is supplied, the core also reports the range of model N across converged perturbations so case loss is not hidden.

Reporting

For manuscript supplements, reviewer responses, or replication handoff, see the companion Gazepoint AOI Robustness Reporting Bundle article, which preserves both adapter settings and the delegated eyeprocess core evidence.

Report the original Gazepoint coordinate columns, source coordinate unit, observation level, screen dimensions used for normalized conversion, viewing geometry for degree-based margins, perturbation values, overlap/screen policies, zero-versus-missing denominator rules, recomputed features, fixed statistical model specification, coefficient/interval ranges, convergence, model-N variation, and failed/non-converged branches.

If eyeprocess is unavailable, the adapter fails directly rather than silently falling back to the older gp3tools margin-sensitivity implementation.

Adapter API map

Use audit_gazepoint_aoi_uncertainty() to validate the Gazepoint-to-core boundary, run_gazepoint_aoi_sensitivity() to delegate the full analysis to eyeprocess, and plot_gazepoint_aoi_sensitivity() for the delegated geometry, assignment, coefficient, and robustness-surface diagnostics.
