Benchmarking gaze-event detectors against reviewed intervals
Source:vignettes/articles/event-detector-benchmarking.Rmd
event-detector-benchmarking.RmdPurpose
Event detectors can disagree because they use different definitions,
thresholds, and model assumptions. gp3tools therefore
separates two questions:
- How do detector outputs agree with one another?
- How closely does each detector reproduce a specified set of reviewed or synthetic reference intervals?
The first question is addressed by
compare_gazepoint_event_detectors(). This article addresses
the second with:
-
create_gazepoint_event_review_template(); -
benchmark_gazepoint_event_detectors(); -
summarise_gazepoint_event_detector_benchmark(); -
plot_gazepoint_event_detector_benchmark().
The reviewed intervals are a reference standard for a particular audit, not a claim that one event definition is universally correct.
Synthetic trace with known fixation intervals
The example below creates three stable gaze periods separated by rapid transitions. The reference table records the intervals used to generate the trace.
set.seed(20260716)
sample_rate <- 100
sample_time <- seq(0, 2.39, by = 1 / sample_rate)
x <- c(
rep(0.20, 80),
seq(0.20, 0.50, length.out = 10),
rep(0.50, 70),
seq(0.50, 0.80, length.out = 10),
rep(0.80, 70)
)
gaze <- data.frame(
USER_ID = "P01",
trial = "T01",
TIME = sample_time,
FPOGX = x + rnorm(length(x), sd = 0.0015),
FPOGY = 0.50 + rnorm(length(x), sd = 0.0015)
)
reviewed <- data.frame(
USER_ID = "P01",
trial = "T01",
review_event_id = 1:3,
start_time = c(0.00, 0.90, 1.70),
end_time = c(0.79, 1.59, 2.39),
event_type = "fixation",
review_status = "accepted"
)
head(gaze)
#> USER_ID trial TIME FPOGX FPOGY
#> 1 P01 T01 0.00 0.1995298 0.4994030
#> 2 P01 T01 0.01 0.2008579 0.5018569
#> 3 P01 T01 0.02 0.1997964 0.5011622
#> 4 P01 T01 0.03 0.2031684 0.4993237
#> 5 P01 T01 0.04 0.2020606 0.4979690
#> 6 P01 T01 0.05 0.2007414 0.4983782
reviewed
#> USER_ID trial review_event_id start_time end_time event_type review_status
#> 1 P01 T01 1 0.0 0.79 fixation accepted
#> 2 P01 T01 2 0.9 1.59 fixation accepted
#> 3 P01 T01 3 1.7 2.39 fixation acceptedA simple trace plot helps verify that the reviewed intervals correspond to the intended stable periods.
plot(
gaze$TIME,
gaze$FPOGX,
type = "l",
xlab = "Time (s)",
ylab = "Horizontal gaze coordinate",
main = "Synthetic fixation and transition structure"
)
for (i in seq_len(nrow(reviewed))) {
rect(
reviewed$start_time[i],
par("usr")[3],
reviewed$end_time[i],
par("usr")[4],
border = NA,
density = 12,
angle = 45
)
}
lines(gaze$TIME, gaze$FPOGX)
Synthetic gaze trace and reviewed fixation intervals.
Run native velocity, HMM, and optional external branches
The comparison layer runs all requested methods on the same sample-level data. The optional external branch is recorded as disabled unless explicitly enabled and eyetools is installed.
comparison <- compare_gazepoint_event_detectors(
gaze,
trial_col = "trial",
methods = c("velocity", "hmm", "eyetools"),
velocity_thresholds = c(5, 10, 20),
min_duration = 50,
hmm_states = 3,
run_optional_eyetools = FALSE
)
comparison$runs
#> detector family status n_events
#> 1 velocity_5 velocity ok 1
#> 2 velocity_10 velocity ok 1
#> 3 velocity_20 velocity ok 1
#> 4 hmm_3_states hmm error NA
#> 5 eyetools_vti eyetools skipped_disabled NA
#> message
#> 1 <NA>
#> 2 <NA>
#> 3 <NA>
#> 4 `HMM output` is missing required column(s): velocity.
#> 5 Set `run_optional_eyetools = TRUE` to run the optional external detector.
comparison$detector_summary
#> detector family threshold n_fixations mean_duration_ms
#> 1 velocity_5 velocity 5 1 2400
#> 2 velocity_10 velocity 10 1 2400
#> 3 velocity_20 velocity 20 1 2400
#> median_duration_ms total_duration_ms
#> 1 2400 2400
#> 2 2400 2400
#> 3 2400 2400Detector failures do not discard successful branches. The benchmark uses only successful detector outputs retained in the comparison object.
Benchmark against the synthetic reference
benchmark <- benchmark_gazepoint_event_detectors(
comparison,
reviewed,
min_overlap = 0.50,
time_unit = "seconds"
)
summarise_gazepoint_event_detector_benchmark(
benchmark,
level = "detector"
)
#> detector family threshold n_sequences n_reviewed n_detected
#> 1 velocity_10 velocity 10 1 3 1
#> 2 velocity_20 velocity 20 1 3 1
#> 3 velocity_5 velocity 5 1 3 1
#> true_positive false_positive false_negative precision recall f1 mean_iou
#> 1 0 1 3 0 0 0 NA
#> 2 0 1 3 0 0 0 NA
#> 3 0 1 3 0 0 0 NA
#> median_iou mean_onset_error_ms mean_abs_onset_error_ms mean_offset_error_ms
#> 1 NA NA NA NA
#> 2 NA NA NA NA
#> 3 NA NA NA NA
#> mean_abs_offset_error_ms mean_duration_error_ms mean_abs_duration_error_ms
#> 1 NA NA NA
#> 2 NA NA NA
#> 3 NA NA NA
#> detection_count_bias
#> 1 -2
#> 2 -2
#> 3 -2The detector-level table reports:
- reviewed and detected event counts;
- true positives, false positives, and false negatives;
- precision, recall, and F1;
- matched-event intersection-over-union;
- onset, offset, and duration error in milliseconds;
- detected-minus-reviewed count bias.
Matching is one-to-one within each participant/trial sequence. Candidate pairs are ordered by decreasing interval intersection-over-union and retained only when neither event has already been matched.
Inspect sequence-level and event-level diagnostics
head(
summarise_gazepoint_event_detector_benchmark(
benchmark,
level = "sequence"
)
)
#> USER_ID trial detector family threshold n_reviewed n_detected
#> 1 P01 T01 velocity_5 velocity 5 3 1
#> 2 P01 T01 velocity_10 velocity 10 3 1
#> 3 P01 T01 velocity_20 velocity 20 3 1
#> true_positive false_positive false_negative precision recall f1 mean_iou
#> 1 0 1 3 0 0 0 NA
#> 2 0 1 3 0 0 0 NA
#> 3 0 1 3 0 0 0 NA
#> median_iou mean_onset_error_ms mean_abs_onset_error_ms mean_offset_error_ms
#> 1 NA NA NA NA
#> 2 NA NA NA NA
#> 3 NA NA NA NA
#> mean_abs_offset_error_ms mean_duration_error_ms mean_abs_duration_error_ms
#> 1 NA NA NA
#> 2 NA NA NA
#> 3 NA NA NA
#> detection_count_bias min_overlap
#> 1 -2 0.5
#> 2 -2 0.5
#> 3 -2 0.5
head(
summarise_gazepoint_event_detector_benchmark(
benchmark,
level = "matches"
)
)
#> [1] USER_ID trial detector
#> [4] family threshold detected_event_id
#> [7] review_event_id detected_start_time detected_end_time
#> [10] reviewed_start_time reviewed_end_time iou
#> [13] onset_error_ms abs_onset_error_ms offset_error_ms
#> [16] abs_offset_error_ms duration_error_ms abs_duration_error_ms
#> <0 rows> (or 0-length row.names)
summarise_gazepoint_event_detector_benchmark(
benchmark,
level = "errors"
)
#> USER_ID trial detector family threshold error_type
#> 1 P01 T01 velocity_5 velocity 5 false_positive
#> 2 P01 T01 velocity_5 velocity 5 false_negative
#> 3 P01 T01 velocity_5 velocity 5 false_negative
#> 4 P01 T01 velocity_5 velocity 5 false_negative
#> 5 P01 T01 velocity_10 velocity 10 false_positive
#> 6 P01 T01 velocity_10 velocity 10 false_negative
#> 7 P01 T01 velocity_10 velocity 10 false_negative
#> 8 P01 T01 velocity_10 velocity 10 false_negative
#> 9 P01 T01 velocity_20 velocity 20 false_positive
#> 10 P01 T01 velocity_20 velocity 20 false_negative
#> 11 P01 T01 velocity_20 velocity 20 false_negative
#> 12 P01 T01 velocity_20 velocity 20 false_negative
#> detected_event_id review_event_id start_time end_time duration_ms
#> 1 1 NA 0.0 2.39 2400
#> 2 NA 1 0.0 0.79 790
#> 3 NA 2 0.9 1.59 690
#> 4 NA 3 1.7 2.39 690
#> 5 1 NA 0.0 2.39 2400
#> 6 NA 1 0.0 0.79 790
#> 7 NA 2 0.9 1.59 690
#> 8 NA 3 1.7 2.39 690
#> 9 1 NA 0.0 2.39 2400
#> 10 NA 1 0.0 0.79 790
#> 11 NA 2 0.9 1.59 690
#> 12 NA 3 1.7 2.39 690The unmatched-event table distinguishes false positives from false negatives, which is useful when reviewing threshold sensitivity or detector-specific failure modes.
Plot benchmark diagnostics
plot_gazepoint_event_detector_benchmark(
benchmark,
plot = "f1"
)
Event-level F1 scores against the reviewed intervals.
plot_gazepoint_event_detector_benchmark(
benchmark,
plot = "precision_recall"
)
Precision and recall against the reviewed intervals.
plot_gazepoint_event_detector_benchmark(
benchmark,
plot = "overlap"
)
Mean interval overlap among matched events.
plot_gazepoint_event_detector_benchmark(
benchmark,
plot = "timing_error"
)
Absolute onset, offset, and duration errors.
Prepare manually reviewed data
Create a CSV-ready template from the sample-level data. One placeholder row is created per sequence by default; reviewers can duplicate rows for additional fixations.
review_template <- create_gazepoint_event_review_template(
gaze,
trial_col = "trial",
rows_per_sequence = 1,
reviewer = "reviewer_1"
)
review_template
#> USER_ID trial review_event_id sequence_start sequence_end start_time end_time
#> 1 P01 T01 1 0 2.39 NA NA
#> event_type review_status reviewer notes
#> 1 fixation pending reviewer_1 <NA>A real review workflow can keep the annotation file outside the package repository:
write.csv(
review_template,
"C:/path/outside/repository/event_review.csv",
row.names = FALSE
)
reviewed_real <- read.csv(
"C:/path/outside/repository/event_review.csv",
stringsAsFactors = FALSE
)
benchmark_real <- benchmark_gazepoint_event_detectors(
comparison_real,
reviewed_real,
min_overlap = 0.50,
time_unit = "seconds"
)For each accepted event, fill start_time and
end_time, preserve the sequence identifiers, and set
review_status to "accepted". Pending or
rejected rows are excluded from the benchmark.
Recommended reporting
A transparent methods supplement should report:
- how reviewed intervals were produced;
- the number of reviewers and any adjudication procedure;
- the overlap threshold used for matching;
- detector settings and sampling rate;
- precision, recall, F1, overlap, and timing error;
- the number and type of failed or skipped detector runs;
- whether conclusions changed across plausible detector definitions.
Benchmark results support sensitivity assessment. They should not be used to claim that a detector uniquely identifies cognitive states or exact mental-event onsets.
