PPG and HRV visual diagnostics

Source: vignettes/articles/ppg-hrv-visual-diagnostics.Rmd
ppg-hrv-visual-diagnostics.Rmd

Purpose

This article demonstrates a plot-rich visual diagnostics workflow for photoplethysmography (PPG), inter-beat intervals (IBI), heart-rate variability (HRV) feature preparation, and respiration-proxy displays in gpbiometrics projects.

The workflow is diagnostic and signal-processing oriented. The figures show raw and filtered PPG traces, baseline-wander checks, candidate peak markers, IBI sequences, implausible-interval audits, Poincare-style interval displays, segment-level HRV summaries, respiration-proxy traces, and compact dashboard-style reporting. They should not be interpreted as direct evidence of health status, clinical state, diagnosis, stress, emotion, attention, workload, autonomic state, or psychological response.

Synthetic PPG stream

The example uses synthetic data so that the article is reproducible and does not depend on private recordings.

participants <- sprintf("P%02d", 1:8)
trials <- seq_len(10)
samples_per_trial <- 750
sampling_rate_hz <- 25
time_s <- seq(0, (samples_per_trial - 1) / sampling_rate_hz, length.out = samples_per_trial)

trial_grid <- expand.grid(
  participant_id = participants,
  trial_id = trials,
  KEEP.OUT.ATTRS = FALSE,
  stringsAsFactors = FALSE
)

make_ppg_trial <- function(participant_id, trial_id) {
  condition <- ifelse(trial_id %% 2 == 0, "dense", "simple")
  participant_shift <- match(participant_id, participants) / 120
  heart_hz <- ifelse(condition == "dense", 1.28, 1.18) + participant_shift + rnorm(1, 0, 0.015)
  respiration_hz <- 0.23 + rnorm(1, 0, 0.01)
  baseline <- 0.08 * sin(2 * pi * time_s / 28) + 0.03 * cos(2 * pi * time_s / 13)
  respiratory_modulation <- 1 + 0.18 * sin(2 * pi * respiration_hz * time_s)
  pulse <- respiratory_modulation * sin(2 * pi * heart_hz * time_s)
  harmonic <- 0.25 * sin(2 * pi * heart_hz * 2 * time_s + 0.6)
  noise <- rnorm(length(time_s), 0, ifelse(condition == "dense", 0.045, 0.035))
  ppg_raw <- 1.0 + baseline + 0.32 * pulse + 0.08 * harmonic + noise
  missing <- runif(length(time_s)) < ifelse(condition == "dense", 0.006, 0.003)
  ppg_raw[missing] <- NA_real_
  data.frame(
    participant_id = participant_id,
    trial_id = trial_id,
    condition = condition,
    time_s = time_s,
    ppg_raw = ppg_raw,
    stringsAsFactors = FALSE
  )
}

ppg <- do.call(
  rbind,
  Map(make_ppg_trial, trial_grid$participant_id, trial_grid$trial_id)
)

head(ppg)
#>       participant_id trial_id condition time_s  ppg_raw
#> P01.1            P01        1    simple   0.00 1.038846
#> P01.2            P01        1    simple   0.04 1.134224
#> P01.3            P01        1    simple   0.08 1.195769
#> P01.4            P01        1    simple   0.12 1.261410
#> P01.5            P01        1    simple   0.16 1.351992
#> P01.6            P01        1    simple   0.20 1.352927

Raw and filtered PPG trace

A raw/filtered trace helps document whether preprocessing changes the signal in a plausible and transparent way.

fill_missing <- function(x) {
  if (!anyNA(x)) return(x)
  idx <- seq_along(x)
  observed <- !is.na(x)
  approx(idx[observed], x[observed], xout = idx, rule = 2)$y
}

smooth_series <- function(x, width) {
  y <- stats::filter(x, rep(1 / width, width), sides = 2)
  y <- as.numeric(y)
  idx <- seq_along(y)
  observed <- !is.na(y)
  y[!observed] <- approx(idx[observed], y[observed], xout = idx[!observed], rule = 2)$y
  y
}

one_trial <- ppg[ppg$participant_id == "P01" & ppg$trial_id == 2, ]
one_trial$ppg_filled <- fill_missing(one_trial$ppg_raw)
one_trial$baseline_est <- smooth_series(one_trial$ppg_filled, width = 151)
one_trial$ppg_filtered <- one_trial$ppg_filled - one_trial$baseline_est

plot(
  one_trial$time_s,
  one_trial$ppg_raw,
  type = "l",
  xlab = "Time (s)",
  ylab = "PPG",
  main = "Raw and filtered PPG"
)
lines(one_trial$time_s, one_trial$ppg_filtered + mean(one_trial$ppg_raw, na.rm = TRUE), lty = 2)
legend("topright", legend = c("raw", "filtered, shifted"), lty = c(1, 2), bty = "n")
Synthetic raw and filtered PPG trace for one participant-trial segment.

Synthetic raw and filtered PPG trace for one participant-trial segment.

Baseline-wander check

Baseline-wander displays support transparent reporting of the preprocessing state used for peak detection or interval extraction.

plot(
  one_trial$time_s,
  one_trial$ppg_filled,
  type = "l",
  xlab = "Time (s)",
  ylab = "PPG",
  main = "Baseline-wander check"
)
lines(one_trial$time_s, one_trial$baseline_est, lty = 2)
legend("topright", legend = c("filled raw", "baseline estimate"), lty = c(1, 2), bty = "n")
Synthetic PPG baseline-wander estimate.

Synthetic PPG baseline-wander estimate.

Candidate PPG peak markers

Candidate peak markers provide a visual audit trail for beat detection. They are algorithmic candidates, not clinical annotations.

detect_simple_peaks <- function(y, time_s, threshold = NULL, refractory_s = 0.45) {
  n <- length(y)
  candidate <- which(y[2:(n - 1)] > y[1:(n - 2)] & y[2:(n - 1)] > y[3:n]) + 1
  if (is.null(threshold)) {
    threshold <- median(y, na.rm = TRUE) + 0.35 * stats::sd(y, na.rm = TRUE)
  }
  candidate <- candidate[y[candidate] >= threshold]
  if (length(candidate) == 0) return(integer())
  keep <- candidate[1]
  for (i in candidate[-1]) {
    if ((time_s[i] - time_s[tail(keep, 1)]) >= refractory_s) {
      keep <- c(keep, i)
    }
  }
  keep
}

peak_idx <- detect_simple_peaks(one_trial$ppg_filtered, one_trial$time_s)
peaks <- data.frame(
  time_s = one_trial$time_s[peak_idx],
  ppg_filtered = one_trial$ppg_filtered[peak_idx]
)

plot(
  one_trial$time_s,
  one_trial$ppg_filtered,
  type = "l",
  xlab = "Time (s)",
  ylab = "Filtered PPG",
  main = "Candidate PPG peaks"
)
points(peaks$time_s, peaks$ppg_filtered, pch = 16)
Synthetic candidate PPG peak markers.

Synthetic candidate PPG peak markers.

IBI interval sequence

The IBI sequence shows the interval series derived from candidate peak times. Implausible intervals should be flagged before HRV feature extraction.

ibi_ms <- diff(peaks$time_s) * 1000
ibi_data <- data.frame(
  interval_id = seq_along(ibi_ms),
  ibi_ms = ibi_ms
)

if (nrow(ibi_data) >= 12) {
  ibi_data$ibi_ms[5] <- 345
  ibi_data$ibi_ms[12] <- 1620
}

plot(
  ibi_data$interval_id,
  ibi_data$ibi_ms,
  type = "b",
  xlab = "Interval index",
  ylab = "IBI (ms)",
  main = "IBI sequence"
)
abline(h = c(400, 1500), lty = 2)
Synthetic IBI sequence from candidate PPG peaks.

Synthetic IBI sequence from candidate PPG peaks.

Implausible interval audit

This audit separates intervals retained for feature extraction from intervals requiring review or correction.

ibi_data$flag_implausible <- ibi_data$ibi_ms < 400 | ibi_data$ibi_ms > 1500

plot(
  ibi_data$interval_id,
  ibi_data$ibi_ms,
  type = "n",
  xlab = "Interval index",
  ylab = "IBI (ms)",
  main = "Implausible interval audit"
)
points(ibi_data$interval_id[!ibi_data$flag_implausible], ibi_data$ibi_ms[!ibi_data$flag_implausible], pch = 16)
points(ibi_data$interval_id[ibi_data$flag_implausible], ibi_data$ibi_ms[ibi_data$flag_implausible], pch = 4)
abline(h = c(400, 1500), lty = 2)
legend("topright", legend = c("retained", "flagged"), pch = c(16, 4), bty = "n")
Synthetic implausible IBI interval audit.

Synthetic implausible IBI interval audit.

Poincare-style interval display

A Poincare-style interval plot is a compact diagnostic for interval-to-interval structure. It is a descriptive interval display, not a clinical interpretation.

ibi_clean <- ibi_data$ibi_ms[!ibi_data$flag_implausible]
poincare <- data.frame(
  ibi_n = ibi_clean[-length(ibi_clean)],
  ibi_next = ibi_clean[-1]
)

plot(
  poincare$ibi_n,
  poincare$ibi_next,
  pch = 16,
  xlab = "IBI[n] (ms)",
  ylab = "IBI[n+1] (ms)",
  main = "Poincare-style interval display"
)
abline(0, 1, lty = 2)
Synthetic Poincare-style IBI display.

Synthetic Poincare-style IBI display.

Segment-level HRV feature summaries

Segment-level features can be reviewed for coverage and distribution before modelling.

make_hrv_features <- function(participant_id, trial_id) {
  condition <- ifelse(trial_id %% 2 == 0, "dense", "simple")
  mean_ibi <- ifelse(condition == "dense", 780, 835) + rnorm(1, 0, 25)
  sdnn <- ifelse(condition == "dense", 42, 52) + rnorm(1, 0, 6)
  rmssd <- ifelse(condition == "dense", 34, 43) + rnorm(1, 0, 5)
  pnn50 <- pmax(0, pmin(100, ifelse(condition == "dense", 18, 27) + rnorm(1, 0, 5)))
  data.frame(
    participant_id = participant_id,
    trial_id = trial_id,
    condition = condition,
    mean_ibi_ms = mean_ibi,
    sdnn_ms = sdnn,
    rmssd_ms = rmssd,
    pnn50_percent = pnn50,
    stringsAsFactors = FALSE
  )
}

hrv_features <- do.call(
  rbind,
  Map(make_hrv_features, trial_grid$participant_id, trial_grid$trial_id)
)

op <- par(mfrow = c(1, 2), mar = c(4, 4, 3, 1))
boxplot(sdnn_ms ~ condition, data = hrv_features, xlab = "Synthetic condition", ylab = "SDNN (ms)", main = "SDNN summary")
boxplot(rmssd_ms ~ condition, data = hrv_features, xlab = "Synthetic condition", ylab = "RMSSD (ms)", main = "RMSSD summary")
Synthetic segment-level HRV feature summaries.

Synthetic segment-level HRV feature summaries.

par(op)

Respiration-proxy trace

A respiration-proxy display can be used to document an algorithmic signal estimate derived from PPG. It should be described as a proxy unless validated against a respiration reference.

abs_envelope <- abs(one_trial$ppg_filtered)
resp_proxy <- smooth_series(abs_envelope, width = 101)
resp_proxy <- resp_proxy - mean(resp_proxy, na.rm = TRUE)

plot(
  one_trial$time_s,
  resp_proxy,
  type = "l",
  xlab = "Time (s)",
  ylab = "Respiration proxy",
  main = "PPG-derived respiration proxy"
)
abline(h = 0, lty = 2)
Synthetic respiration-proxy trace derived from PPG amplitude modulation.

Synthetic respiration-proxy trace derived from PPG amplitude modulation.

Compact PPG/HRV visual diagnostics dashboard

A compact dashboard can combine preprocessing, peak detection, interval audit, and feature-review displays for technical reporting.

op <- par(mfrow = c(2, 2), mar = c(4, 4, 3, 1))

plot(one_trial$time_s, one_trial$ppg_raw, type = "l", xlab = "Time (s)", ylab = "PPG", main = "Raw PPG")
lines(one_trial$time_s, one_trial$baseline_est, lty = 2)

plot(one_trial$time_s, one_trial$ppg_filtered, type = "l", xlab = "Time (s)", ylab = "Filtered PPG", main = "Candidate peaks")
points(peaks$time_s, peaks$ppg_filtered, pch = 16)

plot(ibi_data$interval_id, ibi_data$ibi_ms, type = "b", xlab = "Interval", ylab = "IBI (ms)", main = "IBI audit")
points(ibi_data$interval_id[ibi_data$flag_implausible], ibi_data$ibi_ms[ibi_data$flag_implausible], pch = 4)
abline(h = c(400, 1500), lty = 2)

boxplot(rmssd_ms ~ condition, data = hrv_features, xlab = "Condition", ylab = "RMSSD (ms)", main = "Feature review")
Compact synthetic PPG/HRV visual diagnostics dashboard.

Compact synthetic PPG/HRV visual diagnostics dashboard.


par(op)

Relation to gpbiometrics helpers

The same reporting pattern can be paired with package-level helpers when project data use the expected column contracts.

task representative_helpers
PPG filtering and baseline review filter_gazepoint_ppg_signal(); remove_gazepoint_ppg_baseline_wander()
PPG peak detection detect_gazepoint_ppg_peaks(); plot_gazepoint_ppg_peak_detection()
IBI quality audit audit_gazepoint_ibi_quality(); filter_gazepoint_ibi_implausible()
Beat correction and interval review correct_gazepoint_beats(); summarize_gazepoint_beat_corrections()
HRV feature extraction extract_gazepoint_hrv_features(); summarise_gazepoint_hrv_features()
Respiration-proxy estimation estimate_gazepoint_respiration_from_ppg(); plot_gazepoint_ppg_breathing()
Report outputs create_gazepoint_qc_supplement(); create_gazepoint_biometrics_report_tables()
library(gpbiometrics)

ppg_filtered <- filter_gazepoint_ppg_signal(
  biometric_data,
  ppg_col = "PPG",
  time_col = "TIME_MS",
  output_col = "PPG_FILTERED"
)

peaks <- detect_gazepoint_ppg_peaks(
  ppg_filtered,
  ppg_col = "PPG_FILTERED",
  time_col = "TIME_MS",
  participant_col = "participant_id",
  trial_col = "trial_id"
)

ibi_quality <- audit_gazepoint_ibi_quality(
  biometric_data,
  ibi_col = "IBI",
  participant_col = "participant_id",
  trial_col = "trial_id"
)

hrv_features <- extract_gazepoint_hrv_features(
  biometric_data,
  ibi_col = "IBI",
  participant_col = "participant_id",
  trial_col = "trial_id"
)

plot_gazepoint_ppg_peak_detection(ppg_filtered, peaks = peaks)
plot_gazepoint_ppg_poincare(hrv_features)

Reporting recommendation

For manuscripts, technical supplements, and reviewer-facing reports, describe these figures as PPG, IBI, HRV, respiration-proxy, signal-processing, quality-control, and reproducibility diagnostics. Avoid stronger clinical, health-related, affective, workload-related, stress-related, attentional, or psychological interpretation unless supported by validation, controls, and modelling evidence.
