Event-Detector Multiverse and Inference Robustness • eyeprocess

Why event detection belongs in the analytical record

An event detector converts a continuous gaze stream into a discrete catalogue of fixations, saccades, pursuits, and related events. That conversion is upstream of AOI dwell, fixation count, time to first fixation (TTFF), revisits, transitions, scanpaths, and fixation-locked pupil summaries. A substantive result can therefore depend on the detector family or parameters even when the downstream model is unchanged.

The detector-multiverse workflow asks a focused question:

Would the substantive inference change under another defensible event-detection specification?

The workflow is:

raw gaze
  -> detector specification
  -> event catalogue
  -> AOI assignment
  -> derived features
  -> identical statistical model
  -> inference-stability report

This is not a search for a detector that produces a preferred p-value.

When to use this workflow

Use detector sensitivity analysis when:

fixation/saccade classification is upstream of the outcome used in the paper;
more than one threshold or detector family is scientifically defensible;
vendor events are being compared with research algorithms;
a reviewer asks whether a gaze effect is detector-dependent;
event fragmentation/merging could plausibly affect AOI metrics or scanpaths.

Do not construct arbitrary parameter grids and present them as universal recommendations. Thresholds depend on sampling rate, precision, task, display, head motion, pursuit content, preprocessing, and the scientific question.

Define detector specifications

The core does not silently choose thresholds.

ivt25 <- define_event_detector_spec(
  "ivt25",
  "ivt",
  velocity_threshold = 25,
  minimum_duration_ms = 60,
  maximum_gap_ms = 75,
  sampling_rate = 60,
  coordinate_unit = "degrees"
)

ivt35 <- define_event_detector_spec(
  "ivt35",
  "ivt",
  velocity_threshold = 35,
  minimum_duration_ms = 60,
  maximum_gap_ms = 75,
  sampling_rate = 60,
  coordinate_unit = "degrees"
)

idt_a <- define_event_detector_spec(
  "idt_A",
  "idt",
  dispersion_threshold = 1.2,
  minimum_duration_ms = 80,
  sampling_rate = 60,
  coordinate_unit = "degrees"
)

adaptive <- define_event_detector_spec(
  "adaptive",
  "adaptive_velocity",
  minimum_duration_ms = 60,
  maximum_gap_ms = 75,
  sampling_rate = 60,
  coordinate_unit = "degrees",
  parameters = list(
    noise_factor = 4,
    minimum_velocity_threshold = 20
  )
)

multiverse <- create_detector_multiverse(
  list(ivt25, ivt35, idt_a, adaptive)
)

multiverse$manifest[, c(
  "detector_id",
  "algorithm",
  "velocity_threshold",
  "dispersion_threshold",
  "minimum_duration_ms"
)]
#>   detector_id         algorithm velocity_threshold dispersion_threshold
#> 1    adaptive adaptive_velocity                 NA                   NA
#> 2       idt_A               idt                 NA                  1.2
#> 3       ivt25               ivt                 25                   NA
#> 4       ivt35               ivt                 35                   NA
#>   minimum_duration_ms
#> 1                  60
#> 2                  80
#> 3                  60
#> 4                  60

The built-in adaptive detector is explicitly a robust-MAD reference implementation. It is not labelled as REMoDNaV, Nyström-Holmqvist, Engbert-Kliegl, or another named external algorithm.

Synthetic 60 Hz worked example

The bundled generator is deliberately small, reproducible, and private-data free. It creates a known positive disclosure-dwell effect.

dat <- simulate_detector_multiverse_data(
  n_participants = 4,
  sampling_rate = 60,
  seed = 20260918
)

detected <- run_detector_multiverse(
  dat,
  multiverse,
  continue_on_error = TRUE
)

summarise_detector_events(detected)
#>   detector_id number_of_events number_of_fixations number_of_saccades
#> 1    adaptive               35                  35                  0
#> 2       idt_A               26                  26                  0
#> 3       ivt25               40                  40                  0
#> 4       ivt35               35                  35                  0
#>   mean_fixation_duration_ms median_fixation_duration_ms
#> 1                  423.3333                    400.0000
#> 2                  598.7179                    533.3333
#> 3                  359.1667                    316.6667
#> 4                  423.3333                    400.0000
#>   total_fixation_duration_ms
#> 1                   14816.67
#> 2                   15566.67
#> 3                   14366.67
#> 4                   14816.67

The same raw gaze is processed independently for every specification.

Compare event catalogues structurally

Different detectors do not necessarily produce the same number of rows, so row-by-row comparison is inappropriate. match_detected_events() performs deterministic one-to-one temporal matching using event overlap and onset tolerance.

agreement <- estimate_detector_agreement(detected)
agreement[, c(
  "detector_a",
  "detector_b",
  "matched_event_precision",
  "matched_event_recall",
  "f1",
  "mean_event_overlap"
)]
#>   detector_a detector_b matched_event_precision matched_event_recall        f1
#> 1   adaptive      idt_A               1.0000000            0.7428571 0.8524590
#> 2   adaptive      ivt25               0.8750000            1.0000000 0.9333333
#> 3   adaptive      ivt35               1.0000000            1.0000000 1.0000000
#> 4      idt_A      ivt25               0.6500000            1.0000000 0.7878788
#> 5      idt_A      ivt35               0.7428571            1.0000000 0.8524590
#> 6      ivt25      ivt35               1.0000000            0.8750000 0.9333333
#>   mean_event_overlap
#> 1          0.8716631
#> 2          0.9244693
#> 3          1.0000000
#> 4          0.7744531
#> 5          0.8716631
#> 6          0.9244693

Without an independently justified reference catalogue, these quantities describe agreement, not accuracy.

plot_detector_agreement(detected)

Pairwise temporal agreement among successful fixation catalogues.

Propagate detector choice into AOI features

AOI overlap defaults to "error". If an event belongs to more than one AOI, the analyst must choose a rule explicitly rather than receiving an undocumented first-match assignment.

features <- propagate_detector_to_aoi(
  detected,
  overlap = "error"
)
features <- propagate_detector_to_features(features)

head(features$features[, c(
  "detector_id",
  "participant_id",
  "trial_id",
  "condition_id",
  "aoi_id",
  "fixation_count",
  "dwell_time_ms",
  "ttff_ms",
  "revisits"
)])
#>   detector_id participant_id trial_id condition_id       aoi_id fixation_count
#> 1    adaptive           P001  R001_T1      control   disclosure              1
#> 2    adaptive           P001  R001_T1      control main_content              2
#> 3    adaptive           P001  R001_T2   disclosure   disclosure              1
#> 4    adaptive           P001  R001_T2   disclosure main_content              3
#> 5    adaptive           P002  R002_T1      control   disclosure              1
#> 6    adaptive           P002  R002_T1      control main_content              2
#>   dwell_time_ms  ttff_ms revisits
#> 1      400.0000 550.0000        0
#> 2     1450.0000   0.0000        1
#> 3      783.3333 650.0000        0
#> 4     1100.0000   0.0000        1
#> 5      416.6667 566.6667        0
#> 6     1416.6667   0.0000        1

Zero-event trials are retained. If a trial contains valid gaze but no target fixation, count/dwell can legitimately be zero. If the trial contains no valid gaze, those quantities remain missing rather than being converted to zero.

plot_detector_feature_distributions(
  features,
  feature = "dwell_time_ms",
  aoi_id = "disclosure"
)

Synthetic disclosure-AOI dwell across detector specifications.

Propagate into the same statistical model

The statistical engine is explicit. The example uses stats::lm() through engine = "stats_lm"; mixed models can use lme4_lmer, and specialist estimators can enter through the documented callback contract.

model_spec <- list(
  engine = "stats_lm",
  formula = dwell_time_ms ~ condition_id + participant_id,
  outcome = "dwell_time_ms",
  aoi_id = "disclosure"
)

inference <- run_detector_inference_multiverse(
  features,
  model_spec,
  minimum_valid_fraction = 0.5
)

condition_term <- grep(
  "condition_id",
  inference$coefficients$term,
  value = TRUE
)[1]

stability <- assess_detector_inference_stability(
  inference,
  term = condition_term,
  substantive_threshold = 100,
  direction = "above"
)

stability
#>                     term specifications term_available_specifications
#> 1 condition_iddisclosure              4                             4
#>   model_failure_specifications converged_specifications convergence_rate
#> 1                            0                        4                1
#>   median_estimate estimate_min estimate_max estimate_range same_sign_proportion
#> 1        416.6667     404.1667     420.8333       16.66667                    1
#>   ci_overlap ci_overlap_lower ci_overlap_upper substantive_conclusion_stability
#> 1       TRUE         214.9798         605.4131                                1

Formula models use na.fail. Missing predictors therefore cause an explicit branch failure rather than an unnoticed reduction in N. Non-converged branches are retained diagnostically and excluded from coefficient-distribution summaries.

Model-input audit

Outcome and quality attrition are also explicit. run_detector_inference_multiverse() returns input_audit, one row per planned detector specification. It records input_rows, aoi_selected_rows, quality_excluded_rows, outcome_missing_rows, model_rows_used, and branch status.

inference$input_audit[, c(
  "detector_id",
  "input_rows",
  "aoi_selected_rows",
  "quality_excluded_rows",
  "outcome_missing_rows",
  "model_rows_used",
  "status"
)]
#>   detector_id input_rows aoi_selected_rows quality_excluded_rows
#> 1    adaptive         16                 8                     0
#> 2       idt_A         16                 8                     0
#> 3       ivt25         16                 8                     0
#> 4       ivt35         16                 8                     0
#>   outcome_missing_rows model_rows_used   status
#> 1                    0               8 modelled
#> 2                    0               8 modelled
#> 3                    0               8 modelled
#> 4                    0               8 modelled

Quality and non-finite-outcome exclusions also appear in inference$warnings. The same counts are copied onto coefficient rows when a model is fitted and onto failure rows when fitting cannot proceed. Missing outcomes are never recoded as zero or silently discarded.

Denominator discipline

The stability table uses the declared detector multiverse as the denominator. specifications is the number of planned detector specifications, term_available_specifications counts branches that returned the requested coefficient, and model_failure_specifications counts recorded model-stage failures. Failed fits, missing requested terms, and non-converged branches therefore reduce the reported convergence rate instead of disappearing from the robustness calculation. Custom model callbacks must return at most one row per coefficient term within a detector branch.

plot_detector_coefficient_stability(
  inference,
  term = condition_term
)

Synthetic condition coefficient and confidence interval across detector specifications.

REMoDNaV is an external bridge, not a reimplementation

When REMoDNaV is the intended detector, request it explicitly:

remodnav <- define_event_detector_spec(
  "remodnav",
  "remodnav",
  minimum_duration_ms = 60,
  sampling_rate = 60,
  coordinate_unit = "degrees",
  parameters = list(
    noise_factor = 5
  )
)

eyeprocess calls the installed REMoDNaV command-line implementation. If the executable is unavailable, that branch fails explicitly and no internal approximation is substituted. Pixel data require an explicit px2deg conversion factor; normalized coordinates must be converted before the bridge is used.

What to report

At minimum, report:

the primary detector and its rationale;
every evaluated detector family and parameter specification;
sampling rate and coordinate units;
thresholds, minimum duration, gap/merge rules, smoothing/filtering, and external implementation versions;
AOI definitions and the AOI-overlap rule;
quality rules applied before modelling;
successful, failed, and non-converged branches;
event-count/duration differences and temporal agreement;
sensitivity of the AOI features supporting the claim;
coefficient distributions, intervals, sign stability, and any explicitly declared substantive threshold;
source, preprocessing, detector, AOI, quality, model, and software provenance.

Do not summarize robustness by counting significant p-values.

Visual reporting companion

For a compact plot-first walkthrough, use vignette("event-detector-multiverse-visual-reporting"). It generates a CI-sized set of internal-detector diagnostics covering event counts, temporal agreement, disclosure-AOI dwell, coefficient stability, and model-input row accounting. The visual article uses only built-in detectors so optional external backends do not determine whether the page can build.

The figures should be read as a sequence: event representation → propagated measurement → downstream inference → row/failure accounting. No individual plot is a detector-validity test.

Generate a Markdown report

report <- report_detector_multiverse(
  features,
  inference = inference,
  term = condition_term,
  substantive_threshold = 100
)

cat(substr(report, 1, 800), "...")
#> # Event-detector multiverse report
#>
#> ## Scope
#>
#> This report evaluates whether events, AOI features, and statistical conclusions change across the supplied defensible detector specifications. The specification set is not evidence that omitted detector choices are valid or irrelevant.
#>
#> ## Detector specifications
#>
#> | detector_id | algorithm | velocity_threshold | dispersion_threshold | minimum_duration_ms | maximum_gap_ms | merge_rule | sampling_rate | smoothing | filter | coordinate_unit | implementation | implementation_version | detector_spec_hash |
#> | --- | --- | --- | --- | --- | --- | --- | --- | --- | --- | --- | --- | --- | --- |
#> | adaptive | adaptive_velocity |  |  | 60 | 75 | none | 60 |  |  | degrees | eyeprocess |  | 9f23dbcd2c2acd6720f04aaeacb2a842 |
#> | idt_A | idt |  | 1.2 | 80 |  |  ...

Interpretation boundaries

Detector agreement does not establish event validity. Detector disagreement does not establish which detector is correct. A stable coefficient across a narrow multiverse does not imply stability to omitted preprocessing, AOI, quality, or model choices.

For broader workflow sensitivity, see vignette("multiverse-sensitivity-and-decision-stability"). For the canonical event functions, see ?event_detector_multiverse.

Methodological context includes Dar, Wagner, and Hanke (2021) on REMoDNaV and recent event-detection evaluation work emphasizing signal/task dependence and event-level matching rather than naive row pairing.

R/Python contract parity

eyeprocess and eyeprocesspy use the same detector-spec vocabulary, failure semantics, temporal-matching fixture, propagated feature names, and tidy inference fields. The same JSON contract fixture is exercised by both test suites.

The backend labels differ only where the host ecosystems differ:

Scientific role	R	Python
ordinary linear model	`stats_lm`	`statsmodels_ols`
mixed model	`lme4_lmer`	`statsmodels_mixedlm`
specialist estimator	`callback`	`callback`
REMoDNaV integration	installed REMoDNaV CLI	installed Python REMoDNaV package

These are backend differences, not permission to alter the scientific model between languages. Numerical identity is not required where estimation engines differ; detector definitions, retained observations, model meaning, convergence status, provenance, and semantic output fields are expected to align.

Failure clinic

The companion event-detector-multiverse-visual-reporting vignette provides a plot-first reporting workflow. The event-detector-multiverse-failure-clinic vignette and installed examples/event-detector-multiverse-failure-clinic.R script deliberately exercise detector failure, quality exclusion, outcome missingness, and invalid duplicate-term callback output. Use them to verify that failures remain visible rather than being repaired silently.
