Data Quality plot gallery and reporting clinic

Source: vignettes/data-quality-plot-gallery.Rmd
data-quality-plot-gallery.Rmd
library(eyeprocess)
#> eyeprocess 0.12.0.9000: vendor-neutral eye/process data harmonization with first-class Gazepoint support.

Purpose

This gallery complements the main standardized data-quality guide with visual, manuscript-facing examples. It uses deterministic synthetic validation data, not empirical performance claims.

validation <- simulate_gaze_quality_calibration(
  seed = 20260918,
  samples_per_target = 18,
  nominal_sampling_hz = 60
)

quality <- create_gaze_quality_report(
  validation,
  by = c("profile", "target_id"),
  valid = "valid",
  missing_reason = "missing_reason",
  nominal_sampling_hz = 60,
  bcea_probability = 0.68,
  preprocessing_spec = "synthetic raw validation samples; no interpolation",
  quality_rules = "descriptive review only"
)

center_target <- quality[quality$target_id == 5, ]

Accuracy

plot_gaze_accuracy(center_target)

Higher target-referenced error means recorded gaze is farther from the known target. Accuracy is not precision: a stable offset can be precise but inaccurate.

RMS sample-to-sample precision

plot_gaze_precision(center_target)

RMS-S2S describes successive-sample fluctuation during stable gaze. Do not calculate or interpret it across target changes or intended saccades. The implementation never bridges a missing sample.

BCEA

plot_bcea(center_target)

BCEA summarizes spatial dispersion as an area. The probability level must be reported; the canonical default is 0.68. BCEA is not a target-referenced accuracy statistic.

Sampling intervals

irregular <- validation[
  validation$profile == "irregular_sampling" &
    validation$target_id == 5,
]
plot_sampling_intervals(irregular, time = "timestamp_ms", time_unit = "ms")

Long intervals describe realized timebase irregularity. When a nominal rate is supplied, long_interval_count records anomalously long intervals and dropped_interval_count estimates how many nominal samples those gaps represent. Neither quantity is a direct hardware packet-loss measurement.

Four-panel quality dashboard

The dashboard is a descriptive review surface. It is not a composite score and does not make exclusion decisions.

Review-rule sensitivity

reviewed <- create_gaze_quality_report(
  validation,
  by = c("profile", "target_id"),
  valid = "valid",
  missing_reason = "missing_reason",
  nominal_sampling_hz = 60,
  thresholds = list(
    accuracy_mean = list(max = 1.0),
    valid_sample_fraction = list(min = 0.80)
  )
)

table(reviewed$review_required)
#>
#> FALSE  TRUE
#>    25    29
attr(reviewed, "gaze_quality_provenance")$automatic_exclusion
#> [1] FALSE

Thresholds are study-specific review rules. They do not silently drop trials, participants, or files. A defensible analysis reports the primary rule and then checks whether conclusions change under plausible alternatives.

Reporting checklist

A manuscript should report, where relevant:

  1. coordinate unit and any screen/viewing geometry used for conversion;
  2. validation/check-target procedure and grouping level;
  3. target-referenced accuracy statistic;
  4. exact precision definition (RMS-S2S, SD, and/or BCEA);
  5. BCEA probability when used;
  6. nominal and empirically realized sampling behavior;
  7. operational definition and amount of data loss;
  8. review/exclusion thresholds and numbers affected;
  9. sensitivity analyses when substantive conclusions depend on quality choices.

A compact starting point is:

report_gaze_quality(center_target)
#> [1] "accuracy_mean: mean 0.671, range 0.116-1.388; precision_rms_s2s: mean 0.677, range 0.210-1.570; precision_sd: mean 0.466, range 0.126-1.087; bcea: mean 1.142, range 0.057-3.732; effective_sampling_hz: mean 56.278, range 46.667-60.000; valid_sample_fraction: mean 0.963, range 0.778-1.000; data_loss_fraction: mean 0.037, range 0.000-0.222. Review required for 0/6 analysis units. Thresholds, when supplied, are study-specific review rules and never trigger automatic exclusion."

Limitations

These functions characterize the measurement process. They do not establish attention, engagement, cognitive load, motivation, competence, or clinical status. Synthetic examples demonstrate software behavior; they are not tracker benchmarks and do not define universal exclusion thresholds.
